TRANSFONTANELLE PHOTOACOUSTIC IMAGING: ULTRASOUND TRANSDUCER SELECTION ANALYSIS

Authors: Rayyan Manwar, Tarikul Islam, MD, Seyed Mohsen Ranjbaran, Kamran Avanaki


ABSTRACT

Transfontanelle ultrasound imaging (TFUI) is the conventional approach for diagnosing brain injury in neonates. Despite being the first stage imaging modality, TFUI lacks accuracy in determining the injury at an early stage due to degraded sensitivity and specificity. Therefore, a modality like photoacoustic imaging that combines the advantages of both acoustic and optical imaging can overcome the existing TFUI limitations. Even though a variety of transducers have been used in TFUI, it is essential to identify the transducer specification that is optimal for transfontanelle imaging using the photoacoustic technique. In this study, we evaluated the performance of 6 commercially available ultrasound transducer arrays to identify the optimal characteristics for transfontanelle photoacoustic imaging. We focused on commercially available linear and phased array transducer probes with center frequencies ranging from 2.5MHz to 8.5MHz which covers the entire spectrum of the transducer arrays used for brain imaging. The probes were tested on both in vitro and ex vivo brain tissue, and their performance in terms of transducer resolution, size, penetration depth, sensitivity, signal to noise ratio, signal amplification and reconstructed image quality were evaluated. The analysis of selected transducers in these areas allowed us to determine the optimal transducer for transfontanelle imaging, based on vasculature depth and blood density in tissue using ex vivo sheep brain. The outcome of this evaluation identified the two most suitable ultrasound transducer probes for transfontanelle photoacoustic imaging.

Click HERE to view publication

IN SITU X-RAY-INDUCED ACOUSTIC COMPUTED TOMOGRAPHY WITH A CONTRAST AGENT: A PROOF OF CONCEPT

Authors: Seongwook Choi,1; Sinyoung Park,1; Ayoung Pyo,2; Dong-Yeon Kim,; Jung-Joon Min,4 ; Changho Lee,4,5,6; Chulhong Kim,1,7


ABSTRACT

X-ray-induced acoustic computed tomography (XACT) has shown great potential as a hybrid imaging modality for real-time non-invasive x-ray dosimetry and low-dose three- dimensional (3D) imaging. While promising, one drawback of the XACT system is the underlying low signal-to-noise ratio (SNR), limiting its in vivo clinical use. In this Letter, we propose the first use of a conventional x-ray computed tomography contrast agent, Gastrografin, for improving the SNR of in situ XACT imaging. We obtained 3D volumetric XACT images of a mouse’s stomach with orally injected Gastrografin establishing the proposal’s feasibility. Thus, we believe, in the future, our proposed technique will allow in vivo imaging and expand or complement conventional x-ray modalities, such as radiotherapy and accelerators.

Click HERE to view publication

SIZE-ADJUSTABLE RING-SHAPE PHOTOACOUSTIC TOMOGRAPHY IMAGER IN VIVO

Author(s): Daohuai Jiang1,2,3, Yifei Xu1, Hengrong Lan1,2,3, Yuting Shen1, Yifan Zhang1,Feng Gao1, Li Liu4*,  Fei Gao1,5*


ABSTRACT

Photoacoustic tomography (PAT) has become a novel biomedical imaging modality for scientific research and clinical diagnosis. It combines the advantages of spectroscopic optical absorption contrast and acoustic resolution with deep penetration. In this article, an imaging size-adjustable PAT system is proposed for potential clinical applications such as breast cancer detection and screening, which can adapt to imaging targets with various sizes. Comparing with the conventional PAT setup with a fixed radius ring shape ultrasound transducer (UT) array, the proposed system is more flexible for imaging diverse size targets based on sectorial ultrasound transducer arrays (SUTAs). Four SUTAs form a 128-channel UT array for photoacoustic detection, where each SUTA has 32 elements. Such four SUTAs are controlled by four stepper motors, respectively, and can change their distribution layout position to adapt for various imaging applications. In this proposed system, the radius of the imaging region of interest (ROI) can be adjusted from 50 to 100 mm, which is much more flexible than the conventional PAT system with a full ring UT array. The simulation experiments using the MATLAB k-wave toolbox demonstrate the feasibility of the proposed system. To further validate the proposed system, imaging of pencil leads made phantom, ex-vivo pork breast with indocyanine green (ICG) injected, and in-vivo human wrist, finger and ankle are conducted to prove its feasibility for potential clinical applications

Click HERE to view publication

NON-INVASIVE PHOTOACOUSTIC COMPUTED TOMOGRAPHY OF RAT HEART ANATOMY AND FUNCTION

Author(s): Xin Tong, Li Lin, Peng Hu, Rui Cao, Yang Zhang, Joshua Olick-Gibson, Lihong V. Wang


ABSTRACT

Non-alcoholic fatty liver disease is the most common liver disorder worldwide, which strongly correlates to obesity, diabetes, and metabolic syndromes. Complementary to mainstream liver diagnostic modalities, photoacoustic tomography (PAT) can provide high-speed images with functional optical contrast. However, PAT has not been demonstrated to study fatty liver anatomy with clear volumetric vasculatures. The livers of multiple rats are non-invasively imaged in vivo using the recently developed 3D PAT platform. The system provides isotropically high spatial resolution in 3D space, presenting clear angiographic structures of rat livers without injecting contrast agents. Furthermore, to quantitatively analyze the difference between the livers of lean and obese rats, the authors measured several PAT features and statistical differences between the two groups are observed. In addition to the anatomy, a time-gated strategy is applied to correct respiration-induced motion artifacts and extracted the hemodynamics of major blood vessels during the breathing cycles. This study demonstrates the capabilities of 3D-PAT to reveal both angiographic anatomy and function in rat livers, providing hematogenous information for fatty liver diagnosis. 3D-PAT, as a new tool for preclinical research, warrants further improvements to be transferred to human pediatric liver imaging.

Click HERE to view publication

REAL-TIME, VOLUMETRIC IMAGING OF RADIATION DOSE DELIVERY DEEP INTO THE LIVER DURING CANCER TREATMENT

Authors: Wei Zhang, Ibrahim Oraiqat, Dale Litzenberg, Kai-Wei Chang, Scott Hadley, Noora Ba Sunbul, Martha M. Matuszak,  Christopher J. Tichacek, Eduardo G. Moros, Paul L. Carson, Kyle C. Cuneo, Xueding Wang, & Issam El Naqa


ABSTRACT

Ionizing radiation acoustic imaging (iRAI) allows online monitoring of radiation’s interactions with tissues during radiation therapy, providing real-time, adaptive feedback for cancer treatments. We describe an iRAI volumetric imaging system that enables mapping of the three-dimensional (3D) radiation dose distribution in a complex clinical radiotherapy treatment. The method relies on a two-dimensional matrix array transducer and a matching multi-channel preamplifier board. The feasibility of imaging temporal 3D dose accumulation was first validated in a tissue-mimicking phantom. Next, semiquantitative iRAI relative dose measurements were verified in vivo in a rabbit model. Finally, real-time visualization of the 3D radiation dose delivered to a patient with liver metastases was accomplished with a clinical linear accelerator. These studies demonstrate the potential of iRAI to monitor and quantify the 3D radiation dose deposition during treatment, potentially improving radiotherapy treatment efficacy using real-time adaptive treatment.

Click HERE to view publication

MONITORING NEONATAL BRAIN HEMORRHAGE PROGRESSION BY PHOTOACOUSTIC TOMOGRAPHY

Author(s): Tianqi Shan, Hao Yang, Shixie Jiang, and Huabei Jiang


ABSTRACT

Neonatal brain hemorrhage (NBH) is the most common neurological disorder in neonates and its clinical interventions are very limited. Understanding the pathology of NBH by non-invasive in-vivo characterization of standardized animal models is essential for developing potential treatments. Currently, there is no suitable tool to provide non-invasive, non-ionizing dynamic imaging of neonatal mouse models with high resolution, high contrast, and deep imaging depth. In this study, we implemented a fast 3D photoacoustic tomography (PAT) system suitable for imaging neonatal mouse brains with good image quality and demonstrated its feasibility in non-invasive monitoring of the dynamic process of NBH in the whole neonatal mouse brain. The results present a high resolution and sensitivity for NBH detection. Both morphological and hemodynamic changes of the hematoma were accurately obtained. Our results demonstrated the potential of PAT as a powerful tool for the preclinical study of neonatal brain hemorrhage.

Click HERE to view publication

CHARACTERIZING A PHOTOACOUSTIC AND FLUORESCENCE IMAGING PLATFORM FOR PRECLINICAL MURINE LONGITUDINAL STUDIES

Author(s): Weylan R. Thompson, Hans-Peter F. Brecht, Vassili Ivanov, Anthony M. Yu, Diego S. Dumani, Dylan J. Lawrence, Stanislav Y. Emelianov, Sergey A. Ermilov


ABSTRACT
SIGNIFICANCE

To effectively study preclinical animal models, medical imaging technology must be developed with a high enough resolution and sensitivity to perform anatomical, functional, and molecular assessments. Photoacoustic (PA) tomography provides high resolution and specificity, and fluorescence (FL) molecular tomography provides high sensitivity; the combination of these imaging modes will enable a wide range of research applications to be studied in small animals.

AIM

We introduce and characterize a dual-modality PA and FL imaging platform using in vivo and phantom experiments.

APPROACH

The imaging platform’s detection limits were characterized through phantom studies that determined the PA spatial resolution, PA sensitivity, optical spatial resolution, and FL sensitivity.

Click HERE to view publication

BIODEGRADABLE AND BIOCOMPATIBLE SEMICONDUCTOR NANOCRYSTALS AS NIR-II PHOTOACOUSTIC IMAGING CONTRAST AGENTS

Author(s): Vinoin Devpaul Vincely, Swathi P. Katakam, Kristie Huda, Xingjian Zhong, Joshua C. Kays, Allison M. Dennis, Carolyn L. Bayer


ABSTRACT

Transabdominal imaging using photoacoustics (PA) is limited by optical attenuation of tissue due to high scattering and absorption in the near infrared (NIR) window. Tissue attenuation is lowered when imaging with longer wavelengths in the NIR window (> 950 nm). However, intrinsic optical contrast is limited in this range and exogenous agents such as gold nanorods (AuNRs) prove popular alternatives. AuNRs have unique optical absorption peaks, due to localized surface plasmon resonance (LSPR), which allow tuning to wavelengths with minimal tissue attenuation. However, AuNRs tend to be bulky (> 50 nm) when adjusting peak LSPR to deep NIR wavelengths leading to poor clearance. In this study, we explored PA signal generation of a biodegradable and biocompatible semiconductor contrast agent – Cu-Fe (bornite) nanocrystals. The semiconductor nature of the nanocrystals allows for particles to be small (3-8 nm) facilitating excretion through kidneys. Here, PA signal generation of bornite was compared to two conventional photoacoustic contrast agents – AuNRs and indocyanine green dye. We found that at similar mass concentrations, bornite generated PA signal 5× greater than AuNRs. In-vivo imaging of bornite showed a 2x increase in sensitivity compared to AuNRs at similar volume concentrations.

Click HERE to view publication

IMPROVING PHOTOACOUSTIC IMAGING IN LOW SIGNAL-TO-NOISE RATIO BY USING SPATIAL AND POLARITY COHERENCE

Author(s): Qiuqin Mao, Weiwei Zhao, Xiaoqin Qian, Chao Tao, Xiaojun Liu


ABSTRACT

To suppress the noise and sidelobe of photoacoustic images, a method is proposed combined with spatial coherence and polarity coherence. In this method, PA signals are delayed, multiplied, then performed polarity coherence, and finally summed. The polarity of delayed-and-multiplied signals rather than the amplitude is considered in polarity coherence operation. The polarity coherence factor is calculated based on the standard deviation of the polarity. Then, the factor as weights is applied to the coherent sum output after spatial autocorrelation to finally obtain the image. The simulated and experimental results prove that the noise level can be effectively suppressed due to its relatively low polarity coherence factor. Compared with the delay-and-sum method, the quantitative results in simulations show that the image contrast and full-width at half-maximum of the proposed method increase by about 227.0 % and 56.5 % when the signal-to-noise ratio of the raw signal is 0 dB, respectively. Besides achieving a better image contrast, this method obtains improvements in sidelobe attenuation and has a narrow main lobe.

Click HERE to view publication

DEEP LEARNING ENABLED REAL-TIME PHOTOACOUSTIC TOMOGRAPHY SYSTEM VIA SINGLE DATA ACQUISITION CHANNEL

Author(s): Hengrong Lan, Daohuai Jiang, Feng Gao, Fei Gao


ABSTRACT

Photoacoustic computed tomography (PACT) combines the optical contrast of optical imaging and the penetrability of sonography. In this work, we develop a novel PACT system to provide real-time imaging, which is achieved by a 120-elements ultrasound array only using a single data acquisition (DAQ) channel. To reduce the channel number of DAQ, we superimpose 30 nearby channels’ signals together in the analog domain, and shrinking to 4 channels of data (120/30 = 4). Furthermore, a four-to-one delay-line module is designed to combine these four channels’ data into one channel before entering the single-channel DAQ, followed by decoupling the signals after data acquisition. To reconstruct the image from four superimposed 30-channels’ PA signals, we train a dedicated deep learning model to reconstruct the final PA image. In this paper, we present the preliminary results of phantom and in-vivo experiments, which manifests its robust real-time imaging performance. The significance of this novel PACT system is that it dramatically reduces the cost of multi-channel DAQ module (from 120 channels to 1 channel), paving the way to a portable, low-cost and real-time PACT system.

Click HERE to view publication
